FirePro W5130M vs Radeon HD 5770

When choosing between FirePro W5130M and Radeon HD 5770, it is worth examining the specifications of the models in detail. Do they meet the recommended requirements of modern games and software? Storage capacity, form factor, TDP, available ports, warranty and manufacturer support are all important. For example, the size of a PC case can limit the maximum thickness and length of the card. Often, instead of the factory overclocked card and RGB backlight, it is better to choose a reference model with a more efficient GPU. And make sure that your current power supply unit has the correct connection pins (using adapters is not recommended). This GPUs compare tool is meant to help you to choose the best graphics card for your build. Let's find out the difference between FirePro W5130M and Radeon HD 5770.

FirePro W5130M is a Laptop Graphics Card

Note: FirePro W5130M is only used in laptop graphics. It has lower GPU clock speed compared to the desktop variant, which results in lower power consumption, but also 10-30% lower gaming performance. Check available laptop models with FirePro W5130M here:

Main Specs

  FirePro W5130M Radeon HD 5770
Power consumption (TDP) 108 Watt
Interface PCIe 3.0 x16 PCIe 2.0 x16
Supplementary power connectors 1x 6-pin
Memory type GDDR5 GDDR5
Maximum RAM amount 2 GB 1 GB
Display Connectors No outputs 2x DVI, 1x HDMI, 1x DisplayPort
  Check Price Check Price
  • FirePro W5130M is connected by PCIe 3.0 x16, and Radeon HD 5770 uses PCIe 2.0 x16 interface.
  • FirePro W5130M has 1 GB more memory, than Radeon HD 5770.
  • FirePro W5130M is used in Mobile workstations, and Radeon HD 5770 - in Desktops.
  • FirePro W5130M is build with GCN architecture, and Radeon HD 5770 - with Terascale 2.
  • FirePro W5130M is manufactured by 28 nm process technology, and Radeon HD 5770 - by 40 nm process technology.
  • Memory clock speed of Radeon HD 5770 is 800 MHz higher, than FirePro W5130M.

Game benchmarks

high / 1080p 8−9 8−9
ultra / 1080p 5−6 5−6
QHD / 1440p 0−1 0−1
low / 720p 18−20 18−20
medium / 1080p 10−11 10−11
FirePro W5130M and Radeon HD 5770 have the same average FPS in Assassin's Creed Odyssey.

Full Specs

  FirePro W5130M Radeon HD 5770
Architecture GCN Terascale 2
Code name Tropo Juniper
Type Mobile workstation Desktop
Release date 2 October 2015 13 October 2009
Pipelines 512 800
Core clock speed 850 MHz
Boost Clock 925 MHz
Transistor count 1,500 million 1,040 million
Manufacturing process technology 28 nm 40 nm
Texture fill rate 29.60 34.00
Floating-point performance 947.2 gflops 1,360.0 gflops
Length 208 mm
Memory bus width 128 Bit 128 Bit
Memory clock speed 4000 MHz 4800 MHz
Memory bandwidth 64 GB/s 76.8 GB/s
Shared memory -
DirectX 12 (11_1) 11.2 (11_0)
Shader Model 5.1 5.0
OpenGL 4.6 4.4
OpenCL 1.2 1.2
Vulkan 1.2.131 N/A
Laptop size medium sized
Eyefinity +
AppAcceleration +
