FirePro W600 vs Radeon HD 5770

If you are going to buy a new graphics card and are choosing between FirePro W600 and Radeon HD 5770, there are a couple of things to consider. Cards with more VRAM in general perform better and allow you to play on higher graphics settings. Size also makes a difference. A model with a large heatsink can occupy up to three expansion slots on a motherboard. Be sure you have enough room in your PC case. When comparing GPUs with different architectures, more processing cores and even higher TFLOPS will not always translate to better performance. To help you decide which GPU you need, we have measured frame rates in a number of popular games. For more on how the FirePro W600 stacks up against Radeon HD 5770, check out specs charts below.

FirePro W600 Check Price

Radeon HD 5770 Check Price

Main Specs

	FirePro W600	Radeon HD 5770
Power consumption (TDP)	75 Watt	108 Watt
Interface	PCIe 3.0 x16	PCIe 2.0 x16
Supplementary power connectors	None	1x 6-pin
Memory type	GDDR5	GDDR5
Maximum RAM amount	2 GB	1 GB
Display Connectors	6x mini-DisplayPort	2x DVI, 1x HDMI, 1x DisplayPort
	Check Price	Check Price

Radeon HD 5770 has 44% more power consumption, than FirePro W600.
FirePro W600 is connected by PCIe 3.0 x16, and Radeon HD 5770 uses PCIe 2.0 x16 interface.
FirePro W600 has 1 GB more memory, than Radeon HD 5770.
Both cards are used in Desktops.
FirePro W600 is build with GCN 1.0 architecture, and Radeon HD 5770 - with Terascale 2.
Core clock speed of Radeon HD 5770 is 100 MHz higher, than FirePro W600.
FirePro W600 is manufactured by 28 nm process technology, and Radeon HD 5770 - by 40 nm process technology.
Radeon HD 5770 is 45 mm longer, than FirePro W600.
Memory clock speed of Radeon HD 5770 is 800 MHz higher, than FirePro W600.

Game benchmarks


high / 1080p	8−9	8−9
ultra / 1080p	5−6	5−6
QHD / 1440p	0−1	0−1
low / 720p	18−20	18−20
medium / 1080p	10−11	10−11
FirePro W600 and Radeon HD 5770 have the same average FPS in Assassin's Creed Odyssey.
high / 1080p	14−16	14−16
ultra / 1080p	12−14	12−14
QHD / 1440p	0−1	0−1
low / 720p	27−30	27−30
medium / 1080p	14−16	14−16
FirePro W600 and Radeon HD 5770 have the same average FPS in Battlefield 5.
low / 768p	45−50	45−50
high / 1080p	45−50	45−50
QHD / 1440p	0−1	0−1
FirePro W600 and Radeon HD 5770 have the same average FPS in Call of Duty: Warzone.
low / 768p	150−160	150−160
medium / 768p	120−130	120−130
ultra / 1080p	60−65	60−65
QHD / 1440p	30−35	30−35
4K / 2160p	27−30	27−30
high / 768p	90−95	90−95
FirePro W600 and Radeon HD 5770 have the same average FPS in Counter-Strike: Global Offensive.
low / 768p	55−60	55−60
ultra / 1080p	21−24	21−24
medium / 1080p	45−50	45−50
FirePro W600 and Radeon HD 5770 have the same average FPS in Cyberpunk 2077.
low / 768p	85−90	85−90
medium / 768p	65−70	65−70
ultra / 1080p	35−40	35−40
FirePro W600 and Radeon HD 5770 have the same average FPS in Dota 2.
high / 1080p	10−11	9−10
ultra / 1080p	9−10	9−10
4K / 2160p	4−5	4−5
low / 720p	21−24	21−24
medium / 1080p	10−11	10−11
FirePro W600 and Radeon HD 5770 have the same average FPS in Far Cry 5.
high / 1080p	16−18	16−18
ultra / 1080p	12−14	12−14
low / 720p	65−70	65−70
medium / 1080p	27−30	27−30
FirePro W600 and Radeon HD 5770 have the same average FPS in Fortnite.
high / 1080p	14−16	14−16
ultra / 1080p	12−14	12−14
QHD / 1440p	2−3	2−3
low / 720p	30−35	30−33
medium / 1080p	16−18	16−18
The average gaming FPS of FirePro W600 in Forza Horizon 4 is 6% more, than Radeon HD 5770.
low / 768p	55−60	55−60
medium / 768p	50−55	50−55
high / 1080p	14−16	14−16
ultra / 1080p	7−8	7−8
QHD / 1440p	0−1	0−1
FirePro W600 and Radeon HD 5770 have the same average FPS in Grand Theft Auto V.
high / 1080p	5−6	5−6
ultra / 1080p	4−5	4−5
4K / 2160p	1−2	1−2
low / 720p	14−16	14−16
medium / 1080p	7−8	7−8
FirePro W600 and Radeon HD 5770 have the same average FPS in Metro Exodus.
low / 768p	95−100	95−100
high / 1080p	90−95	90−95
ultra / 1080p	85−90	85−90
medium / 1080p	95−100	95−100
FirePro W600 and Radeon HD 5770 have the same average FPS in Minecraft.
high / 1080p	18−20	18−20
ultra / 1080p	14−16	14−16
low / 720p	35−40	35−40
medium / 1080p	18−20	18−20
FirePro W600 and Radeon HD 5770 have the same average FPS in PLAYERUNKNOWN'S BATTLEGROUNDS.
ultra / 1080p	8−9	8−9
QHD / 1440p	0−1	0−1
low / 720p	14−16	14−16
medium / 1080p	12−14	10−12
The average gaming FPS of FirePro W600 in Red Dead Redemption 2 is 9% more, than Radeon HD 5770.
low / 768p	30−33	27−30
medium / 768p	18−20	18−20
high / 1080p	10−12	10−12
ultra / 1080p	7−8	7−8
4K / 2160p	6−7	6−7
The average gaming FPS of FirePro W600 in The Witcher 3: Wild Hunt is 7% more, than Radeon HD 5770.
low / 768p	85−90	85−90
medium / 768p	45−50	45−50
ultra / 1080p	21−24	21−24
high / 768p	40−45	40−45
FirePro W600 and Radeon HD 5770 have the same average FPS in World of Tanks.

Full Specs

	FirePro W600	Radeon HD 5770
Architecture	GCN 1.0	Terascale 2
Code name	Cape Verde	Juniper
Type	Workstation	Desktop
Release date	13 June 2012	13 October 2009
Pipelines	512	800
Core clock speed	750 MHz	850 MHz
Transistor count	1,500 million	1,040 million
Manufacturing process technology	28 nm	40 nm
Texture fill rate	24.00	34.00
Floating-point performance	768.0 gflops	1,360.0 gflops
Length	163 mm	208 mm
Memory bus width	128 Bit	128 Bit
Memory clock speed	4000 MHz	4800 MHz
Memory bandwidth	64 GB/s	76.8 GB/s
DirectX	12 (11_1)	11.2 (11_0)
Shader Model	5.1	5.0
OpenGL	4.6	4.4
OpenCL	1.2	1.2
Vulkan	1.2.131	N/A
Bitcoin / BTC (SHA256)	94 Mh/s
