GeForce GTX 1660 vs Quadro P5000

When choosing between GeForce GTX 1660 and Quadro P5000, it is worth examining the specifications of the models in detail. Do they meet the recommended requirements of modern games and software? Storage capacity, form factor, TDP, available ports, warranty and manufacturer support are all important. For example, the size of a PC case can limit the maximum thickness and length of the card. Often, instead of the factory overclocked card and RGB backlight, it is better to choose a reference model with a more efficient GPU. And make sure that your current power supply unit has the correct connection pins (using adapters is not recommended). This GPUs compare tool is meant to help you to choose the best graphics card for your build. Let's find out the difference between GeForce GTX 1660 and Quadro P5000.

GeForce GTX 1660 Check Price

Quadro P5000

Main Specs

	GeForce GTX 1660	Quadro P5000
Power consumption (TDP)	120 Watt	100 Watt
Interface	PCIe 3.0 x16	PCIe 3.0 x16
Supplementary power connectors	1x 8-pin	1x 8-pin
Memory type	GDDR5	GDDR5
Maximum RAM amount	6 GB	16 GB
Display Connectors	1x DVI, 1x HDMI, 1x DisplayPort	1x DVI, 4x DisplayPort
	Check Price

GeForce GTX 1660 has 20% more power consumption, than Quadro P5000.
Both video cards are using PCIe 3.0 x16 interface connection to a motherboard.
Quadro P5000 has 10 GB more memory, than GeForce GTX 1660.
Both cards are used in Desktops.
GeForce GTX 1660 is build with Turing architecture, and Quadro P5000 - with Pascal.
Core clock speed of Quadro P5000 is 77 MHz higher, than GeForce GTX 1660.
GeForce GTX 1660 is manufactured by 12 nm process technology, and Quadro P5000 - by 16 nm process technology.
Quadro P5000 is 38 mm longer, than GeForce GTX 1660.
Memory clock speed of Quadro P5000 is 1016 MHz higher, than GeForce GTX 1660.

Game benchmarks


high / 1080p	55−60	55−60
ultra / 1080p	40−45	40−45
QHD / 1440p	30−35	30−35
4K / 2160p	18−20	18−20
low / 720p	80−85	85−90
medium / 1080p	65−70	65−70
The average gaming FPS of Quadro P5000 in Assassin's Creed Odyssey is 2% more, than GeForce GTX 1660.
high / 1080p	90−95	90−95
ultra / 1080p	80−85	80−85
QHD / 1440p	60−65	60−65
4K / 2160p	30−35	30−35
low / 720p	140−150	140−150
medium / 1080p	100−110	100−110
GeForce GTX 1660 and Quadro P5000 have the same average FPS in Battlefield 5.
low / 768p	45−50	45−50
GeForce GTX 1660 and Quadro P5000 have the same average FPS in Call of Duty: Warzone.
low / 768p	250−260	250−260
medium / 768p	230−240	230−240
QHD / 1440p	150−160	150−160
4K / 2160p	100−110	100−110
high / 768p	220−230	220−230
GeForce GTX 1660 and Quadro P5000 have the same average FPS in Counter-Strike: Global Offensive.
low / 768p	70−75	70−75
medium / 1080p	50−55	50−55
GeForce GTX 1660 and Quadro P5000 have the same average FPS in Cyberpunk 2077.
low / 768p	120−130	120−130
medium / 768p	110−120	110−120
ultra / 1080p	110−120	110−120
GeForce GTX 1660 and Quadro P5000 have the same average FPS in Dota 2.
high / 1080p	70−75	75−80
ultra / 1080p	70−75	70−75
QHD / 1440p	45−50	50−55
4K / 2160p	24−27	24−27
low / 720p	110−120	110−120
medium / 1080p	75−80	75−80
The average gaming FPS of Quadro P5000 in Far Cry 5 is 2% more, than GeForce GTX 1660.
high / 1080p	100−110	110−120
ultra / 1080p	85−90	85−90
QHD / 1440p	55−60	55−60
4K / 2160p	21−24	21−24
low / 720p	230−240	230−240
medium / 1080p	160−170	160−170
The average gaming FPS of Quadro P5000 in Fortnite is 0% more, than GeForce GTX 1660.
high / 1080p	95−100	95−100
ultra / 1080p	75−80	75−80
QHD / 1440p	55−60	60−65
4K / 2160p	35−40	40−45
low / 720p	140−150	140−150
medium / 1080p	100−110	100−110
The average gaming FPS of Quadro P5000 in Forza Horizon 4 is 2% more, than GeForce GTX 1660.
low / 768p	160−170	160−170
medium / 768p	150−160	150−160
high / 1080p	110−120	110−120
ultra / 1080p	55−60	55−60
QHD / 1440p	45−50	50−55
The average gaming FPS of Quadro P5000 in Grand Theft Auto V is 0% more, than GeForce GTX 1660.
high / 1080p	45−50	45−50
ultra / 1080p	35−40	35−40
QHD / 1440p	27−30	27−30
4K / 2160p	16−18	18−20
low / 720p	100−110	100−110
medium / 1080p	60−65	60−65
The average gaming FPS of Quadro P5000 in Metro Exodus is 2% more, than GeForce GTX 1660.
low / 768p	120−130	120−130
GeForce GTX 1660 and Quadro P5000 have the same average FPS in Minecraft.
high / 1080p	90−95	95−100
ultra / 1080p	65−70	65−70
4K / 2160p	18−20	18−20
low / 720p	130−140	130−140
medium / 1080p	100−110	100−110
The average gaming FPS of Quadro P5000 in PLAYERUNKNOWN'S BATTLEGROUNDS is 1% more, than GeForce GTX 1660.
high / 1080p	40−45	40−45
ultra / 1080p	27−30	27−30
QHD / 1440p	21−24	21−24
4K / 2160p	14−16	14−16
low / 720p	100−110	100−110
medium / 1080p	65−70	65−70
GeForce GTX 1660 and Quadro P5000 have the same average FPS in Red Dead Redemption 2.
low / 768p	210−220	210−220
medium / 768p	140−150	140−150
high / 1080p	85−90	85−90
ultra / 1080p	45−50	45−50
4K / 2160p	30−35	30−35
GeForce GTX 1660 and Quadro P5000 have the same average FPS in The Witcher 3: Wild Hunt.
low / 768p	140−150	140−150
ultra / 1080p	70−75	70−75
GeForce GTX 1660 and Quadro P5000 have the same average FPS in World of Tanks.

Full Specs

	GeForce GTX 1660	Quadro P5000
Architecture	Turing	Pascal
Code name	Turing TU116	GP104
Type	Desktop	Workstation
Release date	14 March 2019	1 October 2016
Pipelines	1408	2048
Core clock speed	1530 MHz	1607 MHz
Boost Clock	1785 MHz	1733 MHz
Transistor count	6,600 million	7,200 million
Manufacturing process technology	12 nm	16 nm
Texture fill rate	157.1	277.3
Floating-point performance		8,873 gflops
Length	229 mm	267 mm
Memory bus width	192 Bit	256 Bit
Memory clock speed	8000 MHz	9016 MHz
Memory bandwidth	192.1 GB/s	192 GB/s
Shared memory	-	-
DirectX	12 (12_1)	12
Shader Model	6.5	5.1
OpenGL	4.6	4.5
OpenCL	1.2	1.2
Vulkan	1.2.131	1.2.131
CUDA	7.5	6.1
Monero / XMR (CryptoNight)		0.53 kh/s
Optimus		+
Ethereum / ETH (DaggerHashimoto)		21 Mh/s
Display Port		1.4
Mosaic		+
nView Display Management		+
3D Stereo		+
