GeForce GTX 560 Ti vs Radeon R7 260X

In this comparison between GeForce GTX 560 Ti and Radeon R7 260X you will find out which graphics card performs better in today's games. Bear in mind that third-party versions may have more efficient cooling and higher clock speeds. This will increase cards' performance, though not by much. In addition to raw power you should also take into account the dimensions. Thicker models simply will not fit into a small mini-ITX case. The resolution of your monitor also affects the choice, since 4K gameplay requires a more powerful GPU. And don't overspend on the graphics card. Other parts of your build may also need to be upgraded, save some money for the CPU or power supply. For some people GeForce GTX 560 Ti will be the best choice, for others Radeon R7 260X will be their preference. Study the comparison tables below and make your choice.

Main Specs

  GeForce GTX 560 Ti Radeon R7 260X
Power consumption (TDP) 170 Watt 115 Watt
Interface PCIe 2.0 x16 PCIe 3.0 x16
Supplementary power connectors 2x 6-pin 1 x 6-pin
Memory type GDDR5 GDDR5
Maximum RAM amount 1 GB 4 GB
Display Connectors 2x DVI, 1x mini-HDMI 2x DVI, 1x HDMI, 1x DisplayPort
  Check Price Check Price
  • GeForce GTX 560 Ti has 47% more power consumption, than Radeon R7 260X.
  • GeForce GTX 560 Ti is connected by PCIe 2.0 x16, and Radeon R7 260X uses PCIe 3.0 x16 interface.
  • Radeon R7 260X has 3 GB more memory, than GeForce GTX 560 Ti.
  • Both cards are used in Desktops.
  • GeForce GTX 560 Ti is build with Fermi architecture, and Radeon R7 260X - with GCN 2.0.
  • GeForce GTX 560 Ti is manufactured by 40 nm process technology, and Radeon R7 260X - by 28 nm process technology.
  • GeForce GTX 560 Ti is 59 mm longer, than Radeon R7 260X.

Game benchmarks

high / 1080p 16−18 16−18
ultra / 1080p 9−10 9−10
QHD / 1440p 4−5 4−5
low / 720p 30−35 30−35
medium / 1080p 18−20 20−22
GeForce GTX 560 Ti and Radeon R7 260X have the same average FPS in Assassin's Creed Odyssey.

Full Specs

  GeForce GTX 560 Ti Radeon R7 260X
Architecture Fermi GCN 2.0
Code name GF114 Bonaire
Type Desktop Desktop
Release date 25 January 2011 8 October 2013
Pipelines 384 896
Core clock speed 822 MHz
Boost Clock 1000 MHz
Transistor count 1,950 million 2,080 million
Manufacturing process technology 40 nm 28 nm
Texture fill rate 52.67 61.60
Floating-point performance 1,263.4 gflops 1,971 gflops
Length 229 mm 170 mm
Memory bus width 256 Bit 128 Bit
Memory clock speed 2004 MHz
Memory bandwidth 128.3 GB/s 104 GB/s
DirectX 12 (11_0)
Shader Model 5.1 6.3
OpenGL 4.6 4.6
OpenCL 1.1 2.0
Vulkan N/A
CUDA 2.1
FreeSync +
Bus support PCIe 3.0
HDMI +
Bitcoin / BTC (SHA256) 87 Mh/s 225 Mh/s
Eyefinity +
Design reference
DDMA audio +
Decred / DCR (Decred) 0.39 Gh/s
Ethereum / ETH (DaggerHashimoto) 5.16 Mh/s
