GeForce GTX 770 vs Quadro K5200

When choosing between GeForce GTX 770 and Quadro K5200, it is worth examining the specifications of the models in detail. Do they meet the recommended requirements of modern games and software? Storage capacity, form factor, TDP, available ports, warranty and manufacturer support are all important. For example, the size of a PC case can limit the maximum thickness and length of the card. Often, instead of the factory overclocked card and RGB backlight, it is better to choose a reference model with a more efficient GPU. And make sure that your current power supply unit has the correct connection pins (using adapters is not recommended). This GPUs compare tool is meant to help you to choose the best graphics card for your build. Let's find out the difference between GeForce GTX 770 and Quadro K5200.

GeForce GTX 770 Check Price

Quadro K5200 Check Price

Main Specs

	GeForce GTX 770	Quadro K5200
Power consumption (TDP)	230 Watt	150 Watt
Interface	PCIe 3.0 x16	PCIe 3.0 x16
Supplementary power connectors	One 8-pin and one 6-pin	1x 6-pin
Memory type	GDDR5	GDDR5
Maximum RAM amount	2 GB	8 GB
Display Connectors	2x DVI, 1x HDMI, 1x DisplayPort	2x DVI, 2x DisplayPort
	Check Price	Check Price

GeForce GTX 770 has 53% more power consumption, than Quadro K5200.
Both video cards are using PCIe 3.0 x16 interface connection to a motherboard.
Quadro K5200 has 6 GB more memory, than GeForce GTX 770.
Both cards are used in Desktops.
GeForce GTX 770 and Quadro K5200 are build with Kepler architecture.
Core clock speed of GeForce GTX 770 is 379 MHz higher, than Quadro K5200.
GeForce GTX 770 and Quadro K5200 are manufactured by 28 nm process technology.
Quadro K5200 is 257 mm longer, than GeForce GTX 770.
Memory clock speed of GeForce GTX 770 is 1004 MHz higher, than Quadro K5200.

Game benchmarks


high / 1080p	35−40	35−40
ultra / 1080p	21−24	21−24
QHD / 1440p	16−18	16−18
4K / 2160p	10−11	10−11
low / 720p	60−65	60−65
medium / 1080p	40−45	40−45
GeForce GTX 770 and Quadro K5200 have the same average FPS in Assassin's Creed Odyssey.
high / 1080p	55−60	55−60
ultra / 1080p	45−50	45−50
QHD / 1440p	35−40	35−40
4K / 2160p	18−20	18−20
low / 720p	100−110	100−110
medium / 1080p	60−65	60−65
GeForce GTX 770 and Quadro K5200 have the same average FPS in Battlefield 5.
low / 768p	50−55	50−55
QHD / 1440p	0−1	0−1
GeForce GTX 770 and Quadro K5200 have the same average FPS in Call of Duty: Warzone.
low / 768p	250−260	250−260
medium / 768p	220−230	220−230
ultra / 1080p	180−190	180−190
QHD / 1440p	110−120	110−120
4K / 2160p	70−75	70−75
high / 768p	210−220	210−220
GeForce GTX 770 and Quadro K5200 have the same average FPS in Counter-Strike: Global Offensive.
low / 768p	60−65	60−65
medium / 1080p	55−60	55−60
GeForce GTX 770 and Quadro K5200 have the same average FPS in Cyberpunk 2077.
low / 768p	120−130	120−130
medium / 768p	110−120	110−120
ultra / 1080p	100−110	100−110
GeForce GTX 770 and Quadro K5200 have the same average FPS in Dota 2.
high / 1080p	45−50	45−50
ultra / 1080p	40−45	40−45
QHD / 1440p	27−30	27−30
4K / 2160p	14−16	14−16
low / 720p	80−85	80−85
medium / 1080p	45−50	45−50
GeForce GTX 770 and Quadro K5200 have the same average FPS in Far Cry 5.
high / 1080p	60−65	60−65
ultra / 1080p	45−50	45−50
QHD / 1440p	27−30	27−30
4K / 2160p	27−30	27−30
low / 720p	180−190	180−190
medium / 1080p	110−120	110−120
GeForce GTX 770 and Quadro K5200 have the same average FPS in Fortnite.
high / 1080p	60−65	60−65
ultra / 1080p	45−50	45−50
QHD / 1440p	30−35	30−35
4K / 2160p	24−27	24−27
low / 720p	100−110	100−110
medium / 1080p	65−70	65−70
GeForce GTX 770 and Quadro K5200 have the same average FPS in Forza Horizon 4.
low / 768p	140−150	140−150
medium / 768p	120−130	120−130
high / 1080p	70−75	70−75
ultra / 1080p	30−35	30−35
QHD / 1440p	21−24	21−24
GeForce GTX 770 and Quadro K5200 have the same average FPS in Grand Theft Auto V.
high / 1080p	24−27	24−27
ultra / 1080p	20−22	20−22
QHD / 1440p	16−18	16−18
4K / 2160p	8−9	8−9
low / 720p	65−70	65−70
medium / 1080p	30−35	30−35
GeForce GTX 770 and Quadro K5200 have the same average FPS in Metro Exodus.
low / 768p	130−140	130−140
medium / 1080p	120−130	120−130
GeForce GTX 770 and Quadro K5200 have the same average FPS in Minecraft.
ultra / 1080p	14−16	14−16
low / 720p	100−110	100−110
medium / 1080p	18−20	18−20
GeForce GTX 770 and Quadro K5200 have the same average FPS in PLAYERUNKNOWN'S BATTLEGROUNDS.
high / 1080p	24−27	24−27
ultra / 1080p	16−18	16−18
QHD / 1440p	10−11	10−11
4K / 2160p	7−8	7−8
low / 720p	65−70	65−70
medium / 1080p	35−40	35−40
GeForce GTX 770 and Quadro K5200 have the same average FPS in Red Dead Redemption 2.
low / 768p	130−140	130−140
medium / 768p	85−90	85−90
high / 1080p	45−50	45−50
ultra / 1080p	24−27	24−27
4K / 2160p	16−18	16−18
GeForce GTX 770 and Quadro K5200 have the same average FPS in The Witcher 3: Wild Hunt.
low / 768p	90−95	90−95
medium / 768p	60−65	60−65
ultra / 1080p	50−55	50−55
high / 768p	60−65	60−65
GeForce GTX 770 and Quadro K5200 have the same average FPS in World of Tanks.

Full Specs

	GeForce GTX 770	Quadro K5200
Architecture	Kepler	Kepler
Code name	GK104	GK110B
Type	Desktop	Workstation
Release date	30 May 2013	22 July 2014
Pipelines	1536	2304
Core clock speed	1046 MHz	667 MHz
Boost Clock	1085 MHz	771 MHz
Transistor count	3,540 million	7,080 million
Manufacturing process technology	28 nm	28 nm
Texture fill rate	134 billion/sec	148.0
Floating-point performance	3,333 gflops	3,553 gflops
Length	10.5" (26.7 cm)	267 mm
Memory bus width	256 Bit	256 Bit
Memory clock speed	7012 MHz	6008 MHz
Memory bandwidth	224.3 GB/s	192.3 GB/s
DirectX	12 (11_0)	12 (11_1)
Shader Model	5.1	5.1
OpenGL	4.3	4.6
OpenCL	1.2	1.2
Vulkan	1.1.126	1.1.126
CUDA	+	3.5
CUDA cores	1536
Bus support	PCI Express 3.0
Height	4.376" (11.1 cm)
Multi monitor support	4 displays
HDMI	+
HDCP	+
Maximum VGA resolution	2048x1536
Audio input for HDMI	Internal
3D Gaming	+
3D Vision	+
3D Vision Live	+
Bitcoin / BTC (SHA256)	113 Mh/s	226 Mh/s
Ethereum / ETH (DaggerHashimoto)	3.9 Mh/s
Blu Ray 3D	+
Minimum recommended system power	600 Watt
PhysX	+
	Check Price	Check Price
