GeForce RTX 2060 vs Radeon RX Vega 64

When choosing between GeForce RTX 2060 and Radeon RX Vega 64, it is worth examining the specifications of the models in detail. Do they meet the recommended requirements of modern games and software? Storage capacity, form factor, TDP, available ports, warranty and manufacturer support are all important. For example, the size of a PC case can limit the maximum thickness and length of the card. Often, instead of the factory overclocked card and RGB backlight, it is better to choose a reference model with a more efficient GPU. And make sure that your current power supply unit has the correct connection pins (using adapters is not recommended). This GPUs compare tool is meant to help you to choose the best graphics card for your build. Let's find out the difference between GeForce RTX 2060 and Radeon RX Vega 64.

GeForce RTX 2060 Check Price

Radeon RX Vega 64 Check Price

Main Specs

	GeForce RTX 2060	Radeon RX Vega 64
Power consumption (TDP)	160 Watt	295 Watt
Interface	PCIe 3.0 x16	PCIe 3.0 x16
Supplementary power connectors	1x 8-pin	2x 8-pin
Memory type	GDDR6	HBM2
Maximum RAM amount	6 GB	8 GB
Display Connectors	1x DVI, 1x HDMI, 2x DisplayPort, 1x USB Type-C	1x HDMI, 3x DisplayPort
	Check Price	Check Price

Radeon RX Vega 64 has 84% more power consumption, than GeForce RTX 2060.
Both video cards are using PCIe 3.0 x16 interface connection to a motherboard.
Radeon RX Vega 64 has 2 GB more memory, than GeForce RTX 2060.
Both cards are used in Desktops.
GeForce RTX 2060 is build with Turing architecture, and Radeon RX Vega 64 - with Vega.
Core clock speed of Radeon RX Vega 64 is 310 MHz higher, than GeForce RTX 2060.
GeForce RTX 2060 is manufactured by 12 nm process technology, and Radeon RX Vega 64 - by 14 nm process technology.
Radeon RX Vega 64 is 50 mm longer, than GeForce RTX 2060.
Memory clock speed of GeForce RTX 2060 is 13055 MHz higher, than Radeon RX Vega 64.

Game benchmarks


high / 1080p	65−70	65−70
ultra / 1080p	45−50	50−55
QHD / 1440p	40−45	40−45
4K / 2160p	24−27	24−27
low / 720p	90−95	90−95
medium / 1080p	75−80	80−85
The average gaming FPS of Radeon RX Vega 64 in Assassin's Creed Odyssey is 3% more, than GeForce RTX 2060.
high / 1080p	100−110	100−110
ultra / 1080p	95−100	95−100
QHD / 1440p	75−80	75−80
4K / 2160p	40−45	40−45
low / 720p	150−160	150−160
medium / 1080p	110−120	120−130
The average gaming FPS of Radeon RX Vega 64 in Battlefield 5 is 2% more, than GeForce RTX 2060.
low / 768p	45−50	45−50
GeForce RTX 2060 and Radeon RX Vega 64 have the same average FPS in Call of Duty: Warzone.
low / 768p	250−260	250−260
medium / 768p	230−240	230−240
QHD / 1440p	150−160	150−160
4K / 2160p	100−110	100−110
high / 768p	220−230	220−230
GeForce RTX 2060 and Radeon RX Vega 64 have the same average FPS in Counter-Strike: Global Offensive.
low / 768p	70−75	70−75
medium / 1080p	50−55	50−55
GeForce RTX 2060 and Radeon RX Vega 64 have the same average FPS in Cyberpunk 2077.
low / 768p	120−130	120−130
medium / 768p	110−120	110−120
GeForce RTX 2060 and Radeon RX Vega 64 have the same average FPS in Dota 2.
high / 1080p	85−90	90−95
ultra / 1080p	80−85	85−90
QHD / 1440p	60−65	65−70
4K / 2160p	30−35	35−40
low / 720p	110−120	120−130
medium / 1080p	90−95	95−100
The average gaming FPS of Radeon RX Vega 64 in Far Cry 5 is 7% more, than GeForce RTX 2060.
high / 1080p	130−140	130−140
ultra / 1080p	100−110	100−110
QHD / 1440p	70−75	70−75
4K / 2160p	21−24	21−24
low / 720p	250−260	250−260
medium / 1080p	170−180	170−180
GeForce RTX 2060 and Radeon RX Vega 64 have the same average FPS in Fortnite.
high / 1080p	110−120	110−120
ultra / 1080p	90−95	95−100
QHD / 1440p	70−75	75−80
4K / 2160p	45−50	50−55
low / 720p	160−170	160−170
medium / 1080p	120−130	120−130
The average gaming FPS of Radeon RX Vega 64 in Forza Horizon 4 is 2% more, than GeForce RTX 2060.
low / 768p	170−180	170−180
medium / 768p	160−170	160−170
high / 1080p	120−130	120−130
ultra / 1080p	70−75	70−75
QHD / 1440p	60−65	65−70
The average gaming FPS of Radeon RX Vega 64 in Grand Theft Auto V is 0% more, than GeForce RTX 2060.
high / 1080p	55−60	55−60
ultra / 1080p	45−50	45−50
QHD / 1440p	35−40	35−40
4K / 2160p	21−24	21−24
low / 720p	120−130	120−130
medium / 1080p	75−80	80−85
The average gaming FPS of Radeon RX Vega 64 in Metro Exodus is 1% more, than GeForce RTX 2060.
low / 768p	120−130	120−130
GeForce RTX 2060 and Radeon RX Vega 64 have the same average FPS in Minecraft.
high / 1080p	110−120	120−130
ultra / 1080p	85−90	90−95
4K / 2160p	18−20	18−20
low / 720p	140−150	150−160
medium / 1080p	130−140	130−140
The average gaming FPS of Radeon RX Vega 64 in PLAYERUNKNOWN'S BATTLEGROUNDS is 5% more, than GeForce RTX 2060.
high / 1080p	50−55	55−60
ultra / 1080p	30−35	35−40
QHD / 1440p	27−30	27−30
4K / 2160p	18−20	18−20
low / 720p	120−130	120−130
medium / 1080p	80−85	85−90
The average gaming FPS of Radeon RX Vega 64 in Red Dead Redemption 2 is 5% more, than GeForce RTX 2060.
low / 768p	250−260	250−260
medium / 768p	180−190	180−190
high / 1080p	100−110	110−120
ultra / 1080p	60−65	60−65
4K / 2160p	40−45	40−45
The average gaming FPS of Radeon RX Vega 64 in The Witcher 3: Wild Hunt is 1% more, than GeForce RTX 2060.
low / 768p	200−210	210−220
ultra / 1080p	95−100	100−110
The average gaming FPS of Radeon RX Vega 64 in World of Tanks is 5% more, than GeForce RTX 2060.

Full Specs

	GeForce RTX 2060	Radeon RX Vega 64
Architecture	Turing	Vega
Code name	Turing TU106	Vega
Type	Desktop	Desktop
Release date	6 January 2019	14 August 2017
Pipelines	1920	4096
Core clock speed	1320 MHz	1630 MHz
Boost Clock	1620 MHz	1546 MHz
Transistor count	10,800 million	12,500 million
Manufacturing process technology	12 nm	14 nm
Texture fill rate	201.6	395.8
Floating-point performance		13,353 gflops
Length	229 mm	279 mm
Memory bus width	192 Bit	2048 Bit
Memory clock speed	14000 MHz	945 MHz
Memory bandwidth	336.0 GB/s	483.8 GB/s
Shared memory	-	-
G-SYNC support	+
VR Ready	+
DirectX	12	12 (12_1)
Shader Model	6.5	6.4
OpenGL	4.6	4.6
OpenCL	1.2	2.0
Vulkan	1.2.131	1.1.125
CUDA	7.5
Monero / XMR (CryptoNight)		1.9 kh/s
Ethereum / ETH (DaggerHashimoto)		31.5 Mh/s
