    Iris Graphics 5100 vs Radeon RX 560

    If you are going to buy a new graphics card and are choosing between Iris Graphics 5100 and Radeon RX 560, there are a couple of things to consider. Cards with more VRAM in general perform better and allow you to play on higher graphics settings. Size also makes a difference. A model with a large heatsink can occupy up to three expansion slots on a motherboard. Be sure you have enough room in your PC case. When comparing GPUs with different architectures, more processing cores and even higher TFLOPS will not always translate to better performance. To help you decide which GPU you need, we have measured frame rates in a number of popular games. For more on how the Iris Graphics 5100 stacks up against Radeon RX 560, check out specs charts below.
    Iris Graphics 5100 Check Price
    Radeon RX 560 Check Price

    Iris Graphics 5100 is a Laptop Graphics Card

    Note: Iris Graphics 5100 is only used in laptop graphics. It has lower GPU clock speed compared to the desktop variant, which results in lower power consumption, but also 10-30% lower gaming performance. Check available laptop models with Iris Graphics 5100 here:

    Iris Graphics 5100 Laptops

    Main Specs

      Iris Graphics 5100 Radeon RX 560
    Power consumption (TDP) 30 Watt 75 Watt
    Interface PCIe 1.0 x16 PCIe 3.0 x8
    Supplementary power connectors None
    Memory type System Shared GDDR5
    Maximum RAM amount 4 GB
    Display Connectors No outputs 1x DVI, 1x HDMI, 1x DisplayPort
      Check Price Check Price
    • Radeon RX 560 has 150% more power consumption, than Iris Graphics 5100.
    • Iris Graphics 5100 is connected by PCIe 1.0 x16, and Radeon RX 560 uses PCIe 3.0 x8 interface.
    • Iris Graphics 5100 is used in Laptops, and Radeon RX 560 - in Desktops.
    • Iris Graphics 5100 is build with Gen. 7.5 Haswell architecture, and Radeon RX 560 - with GCN 4.0.
    • Core clock speed of Radeon RX 560 is 975 MHz higher, than Iris Graphics 5100.
    • Iris Graphics 5100 is manufactured by 22 nm process technology, and Radeon RX 560 - by 14 nm process technology.

    Game benchmarks

    high / 1080p 3−4 18−20
    ultra / 1080p 1−2 10−12
    QHD / 1440p 0−1 5−6
    4K / 2160p − 4−5
    low / 720p 14−16 35−40
    medium / 1080p 5−6 21−24
    The average gaming FPS of Radeon RX 560 in Assassin's Creed Odyssey is 266% more, than Iris Graphics 5100.

    Full Specs

      Iris Graphics 5100 Radeon RX 560
    Architecture Gen. 7.5 Haswell GCN 4.0
    Code name Haswell GT3 Polaris 21
    Type Laptop Desktop
    Release date 5 June 2013 18 April 2017
    Pipelines 40 1024
    Core clock speed 200 MHz 1175 MHz
    Boost Clock 1200 MHz 1275 MHz
    Transistor count 1,300 million 3,000 million
    Manufacturing process technology 22 nm 14 nm
    Texture fill rate 48.00 81.60
    Floating-point performance 2,611 gflops
    Length 170 mm
    Memory bus width 64/128 Bit 128 Bit
    Memory clock speed 7000 MHz
    Memory bandwidth 112.0 GB/s
    Shared memory +
    DirectX 12 (11_1) 12 (12_0)
    Shader Model 5.1 6.4
    OpenGL 4.3 4.6
    OpenCL 1.2 2.0
    Vulkan 1.1.80 1.2.131
    Quick Sync +
      Check Price Check Price
