Quadro M4000 vs Quadro M4000M

When comparing Quadro M4000 and Quadro M4000M, we look primarily at benchmarks and game tests. But it is not only about the numbers. Often you can find third-party models with higher clock speeds, better cooling, or a customizable RGB lighting. Not all of them will have all the features you need. Another thing to consider is the port selection. Most graphics cards have at least one DisplayPort and HDMI interface, but some monitors require DVI. Before you buy, check the TDP of the graphics card - this characteristic will help you estimate the consumption of the graphics card. You may even have to upgrade your PSU to meet its requirements. An important factor when choosing between Quadro M4000 and Quadro M4000M is the price. Does the additional cost justify the performance hit? Our comparison should help you make the right decision.

Quadro M4000 Check Price

Quadro M4000M Check Price

Quadro M4000M is a Laptop Graphics Card

Note: Quadro M4000M is only used in laptop graphics. It has lower GPU clock speed compared to the desktop variant, which results in lower power consumption, but also 10-30% lower gaming performance. Check available laptop models with Quadro M4000M here:

Quadro M4000M Laptops

Main Specs

	Quadro M4000	Quadro M4000M
Power consumption (TDP)	120 Watt	100 Watt
Interface	PCIe 3.0 x16	PCIe 3.0 x16
Supplementary power connectors	1 x 6-pin	None
Memory type	GDDR5	GDDR5
Maximum RAM amount	8 GB	4 GB
Display Connectors	4x DisplayPort	No outputs
	Check Price	Check Price

Quadro M4000 has 20% more power consumption, than Quadro M4000M.
Both video cards are using PCIe 3.0 x16 interface connection to a motherboard.
Quadro M4000 has 4 GB more memory, than Quadro M4000M.
Quadro M4000 is used in Desktops, and Quadro M4000M - in Mobile workstations.
Quadro M4000 is build with Maxwell 2.0 architecture, and Quadro M4000M - with Maxwell.
Core clock speed of Quadro M4000M is 202 MHz higher, than Quadro M4000.
Quadro M4000 and Quadro M4000M are manufactured by 28 nm process technology.
Memory clock speed of Quadro M4000 is 996 MHz higher, than Quadro M4000M.

Game benchmarks


high / 1080p	35−40	35−40
ultra / 1080p	21−24	21−24
QHD / 1440p	16−18	16−18
4K / 2160p	10−11	10−11
low / 720p	60−65	60−65
medium / 1080p	40−45	40−45
Quadro M4000 and Quadro M4000M have the same average FPS in Assassin's Creed Odyssey.
high / 1080p	55−60	55−60
ultra / 1080p	45−50	45−50
QHD / 1440p	35−40	35−40
4K / 2160p	18−20	18−20
low / 720p	100−110	100−110
medium / 1080p	60−65	60−65
Quadro M4000 and Quadro M4000M have the same average FPS in Battlefield 5.
low / 768p	50−55	50−55
QHD / 1440p	0−1	0−1
Quadro M4000 and Quadro M4000M have the same average FPS in Call of Duty: Warzone.
low / 768p	250−260	250−260
medium / 768p	220−230	220−230
ultra / 1080p	180−190	180−190
QHD / 1440p	110−120	110−120
4K / 2160p	70−75	70−75
high / 768p	210−220	210−220
Quadro M4000 and Quadro M4000M have the same average FPS in Counter-Strike: Global Offensive.
low / 768p	60−65	60−65
medium / 1080p	55−60	55−60
Quadro M4000 and Quadro M4000M have the same average FPS in Cyberpunk 2077.
low / 768p	120−130	120−130
medium / 768p	110−120	110−120
ultra / 1080p	100−110	100−110
Quadro M4000 and Quadro M4000M have the same average FPS in Dota 2.
high / 1080p	45−50	45−50
ultra / 1080p	40−45	40−45
QHD / 1440p	27−30	27−30
4K / 2160p	14−16	14−16
low / 720p	80−85	80−85
medium / 1080p	45−50	45−50
Quadro M4000 and Quadro M4000M have the same average FPS in Far Cry 5.
high / 1080p	60−65	60−65
ultra / 1080p	45−50	45−50
QHD / 1440p	27−30	27−30
4K / 2160p	27−30	27−30
low / 720p	180−190	180−190
medium / 1080p	110−120	110−120
Quadro M4000 and Quadro M4000M have the same average FPS in Fortnite.
high / 1080p	60−65	60−65
ultra / 1080p	45−50	45−50
QHD / 1440p	30−35	30−35
4K / 2160p	24−27	24−27
low / 720p	100−110	100−110
medium / 1080p	65−70	65−70
Quadro M4000 and Quadro M4000M have the same average FPS in Forza Horizon 4.
low / 768p	140−150	140−150
medium / 768p	120−130	120−130
high / 1080p	70−75	70−75
ultra / 1080p	30−35	30−35
QHD / 1440p	21−24	21−24
Quadro M4000 and Quadro M4000M have the same average FPS in Grand Theft Auto V.
high / 1080p	24−27	24−27
ultra / 1080p	20−22	20−22
QHD / 1440p	16−18	16−18
4K / 2160p	8−9	8−9
low / 720p	65−70	65−70
medium / 1080p	30−35	30−35
Quadro M4000 and Quadro M4000M have the same average FPS in Metro Exodus.
low / 768p	130−140	130−140
medium / 1080p	120−130	120−130
Quadro M4000 and Quadro M4000M have the same average FPS in Minecraft.
ultra / 1080p	14−16	14−16
low / 720p	100−110	100−110
medium / 1080p	18−20	18−20
Quadro M4000 and Quadro M4000M have the same average FPS in PLAYERUNKNOWN'S BATTLEGROUNDS.
high / 1080p	24−27	24−27
ultra / 1080p	16−18	16−18
QHD / 1440p	10−11	10−11
4K / 2160p	7−8	7−8
low / 720p	65−70	65−70
medium / 1080p	35−40	35−40
Quadro M4000 and Quadro M4000M have the same average FPS in Red Dead Redemption 2.
low / 768p	130−140	130−140
medium / 768p	85−90	85−90
high / 1080p	45−50	45−50
ultra / 1080p	24−27	24−27
4K / 2160p	16−18	16−18
Quadro M4000 and Quadro M4000M have the same average FPS in The Witcher 3: Wild Hunt.
low / 768p	90−95	90−95
medium / 768p	60−65	60−65
ultra / 1080p	50−55	50−55
high / 768p	60−65	60−65
Quadro M4000 and Quadro M4000M have the same average FPS in World of Tanks.

Full Specs

	Quadro M4000	Quadro M4000M
Architecture	Maxwell 2.0	Maxwell
Code name	GM204	GM204
Type	Workstation	Mobile workstation
Release date	29 June 2015	2 October 2015
Pipelines	1664	1,280
Core clock speed	773 MHz	975 MHz
Boost Clock		1013 MHz
Transistor count	5,200 million	5,200 million
Manufacturing process technology	28 nm	28 nm
Texture fill rate	80.39	78.00
Floating-point performance	2,573 gflops	2,496 gflops
Length	241 mm
Memory bus width	256 Bit	256 Bit
Memory clock speed	6008 MHz	5012 MHz
Memory bandwidth		160 GB/s
Shared memory		-
DirectX	12	12
Shader Model	5	5.0
OpenGL	4.5	4.5
OpenCL	1.2	1.2
Vulkan	+	1.1.126
CUDA	5.2	5.2
SLI options	+
Bitcoin / BTC (SHA256)	299 Mh/s	251 Mh/s
Laptop size		large
Optimus		+
Display Port		1.2
3D Vision Pro	+	+
Mosaic	+	+
nView Display Management		+
Width	1" (2.5 cm)
Number of simultaneous displays	4
nView Desktop Management	+
Multi-display synchronization	Quadro Sync
High-Performance Video I/O6	+
